FBox-5G
Brand:SIWEIJUNLI
Series:FBox series
Service Hotline:13775081082
Overview:FBox-5G IoT gateway supports 5G/4G/GNSS/wired network, supports 350+industrial protocol access, supports VPN transparent transmission, supports PLC program upload, download, and monitoring, and provides remote operation and maintenance solutions.
Series:FBox series
Service Hotline:13775081082
Overview:FBox-5G IoT gateway supports 5G/4G/GNSS/wired network, supports 350+industrial protocol access, supports VPN transparent transmission, supports PLC program upload, download, and monitoring, and provides remote operation and maintenance solutions.
♦Special note: slightly different from the actual product.
♦Customization: Supports non-standard customization.
♦Inventory delivery: National delivery guarantee!
♦Kind reminder: Non quality issues do not support returns!
♦Customization: Supports non-standard customization.
♦Inventory delivery: National delivery guarantee!
♦Kind reminder: Non quality issues do not support returns!
DESCRIPTION
Hardware parameters
CPU 800MHz ARM Cortex-A8 Memory 256MB Flash+256MB DDR3 IO Port nothing working voltage DC 24V, working range DC 18V~28V Mechanical structure aluminium alloy Overall size 138mm × 95mm × 45mm weight About 500g Installation method Standard guide rail installation antenna 5G antenna (standard), GPS antenna (customer option)
Communication parameters
Networking methods 5G/4G/GNSS/wired network Network format and frequency band 5GNR: n1/n28/n41/n77/n78/n79 4G LTE FDD: B1/B2/B3/B5/B7/B8/B20/B28 4G LTE TDD: B34/B38/39/B40/B41 WCDMA: B1/B3/B5/B8 Ethernet One adaptive 10M/100M WAN port; 4-way adaptive 10M/100M LAN port Serial communication port COM1: RS232/RS485/RS422; COM2/COM4: RS485; COM3: RS232 USB port 1 USB Slave TypeC interface; 1 USB Host 2.0 port
Software parameters
Real time data monitoring support Historical data recording support Ordinary transmission support VPN transparent transmission support Edge computing support API interface support Management and remote maintenance Support for remote firmware upgrade, support for importing and exporting configuration files Data monitoring 1000 points Alarm Entry 400 points History Entry 200 points Historical data storage time 180 days
