Product brand: Siwei Junli

Series: Electromagnetic tensioner

Service hotline: 13775081082

Overview KX-1000 Technical specifications:

1. Tension range 3CN to 30CN. Tension fluctuation range 3~30CN士1CN.

2. Speed range 0-500m/min.

3. tension device backup function: Ethernet networking and running signal light display, individual open and stop switch, using horizontal pin wheel type yarn, 24VDC power supply, RS485 communication. The system includes man-machine interface, can set the tension, each ingot tension display, position state display, tension control can be divided into starting tension, running tension and brake tension.
